Monitor traffic through Agent Gateway

Use this page to learn how to view logs and monitor requests and access control decisions for traffic routed through your Agent Gateway deployment.

Logging

Agent Gateway logs are generated using the networkservices.googleapis.com/Gateway monitored resource.

You can use these logs to monitor access requests to the gateway. This includes the logs created when Agent Gateway is deployed in dry-run mode.

View logs for a specific gateway

To view the logs for a specific gateway, complete the following steps.

Console query

  1. In the Google Cloud console, go to the Logs Explorer page.

    Go to Logs Explorer

  2. Click the Show query toggle.

  3. Paste the following into the query field.

    resource.type="networkservices.googleapis.com/Gateway"
resource.labels.location="REGION"
resource.labels.gateway_name="AGENT_GATEWAY_NAME"

    Replace the following:

    • REGION: The region of your gateway.
    • AGENT_GATEWAY_NAME: The name of your gateway.

  4. Click Run query.

What is logged

Agent Gateway log entries contain information useful for monitoring and debugging traffic to and from your gateway.

Field Field format Field type: Required or Optional Description
severity
insertID
timestamp
receiveTimestamp
trace
traceSampled
logName		 LogEntry Required The general fields as described in a log entry.
httpRequest HttpRequest Required A common protocol for logging HTTP requests.
resource MonitoredResource Required

The MonitoredResource is the resource type associated with a log entry. The resource type for Agent Gateway is networkservices.googleapis.com/Gateway.
jsonPayload object (Struct format) Required

The log entry payload that is expressed as a JSON object. The JSON object contains the following Agent Gateway fields:

  • agentGatewayInfo: Includes information about Agent Gateway requests.

    • mcpInfo: Includes information about the MCP method of the request (for example, "tools/list" or "tools/call") and the primary parameter associated with the method, if any. For example, in the case of the "tools/call" method the parameter is the tool name.
    • agentRegistryResource: The Agent Registry resource name of the MCP server, agent, or endpoint that was matched to the request.

  • You can also inspect the details of the serviceEntensionsInfo field for information about the authorization extension (IAP, Model Armor, or other) that handled the request.

Monitoring

Agent Gateway exports some Service Extensions metrics to Cloud Monitoring. If you're delegating authorization to Service Extensions, you can use these metrics to monitor traffic to and from your extension. For details, see Logging and monitoring for Cloud Load Balancing callouts.

Observability dashboard

Agent Gateway provides an observability dashboard that lets you monitor, audit, and debug traffic routed through your gateways:

  • Scorecards: Track the total number of attempted authorizations, authorization failures, and requests per second.
  • Charts: Visualize authorization failure rates (%) and requests per second over time.
  • Egress traffic logs: Review detailed logs for egress queries, including 403 denials, traffic to unregistered endpoints, and overall traffic trends.

Use the following steps to access the observability dashboard for a gateway in the Google Cloud console:

  1. In the Google Cloud console, go to the Agent Gateway page.

    Go to Agent Gateway

  2. Click the name of the gateway that you want to monitor.

  3. Click the Observability tab.

Dashboard data requirements

The Agent Gateway observability dashboard uses Observability Analytics to display data. If the dashboard isn't loading data, ensure that you upgrade the _Default log bucket to use Observability Analytics. The dashboard retrieves data from the _Default bucket's _AllLogs view.

What's next

Codelab

Learn how to govern agentic workloads with Agent Gateway on Gemini Enterprise Agent Platform.

Troubleshooting

Learn how to troubleshoot Agent Gateway connectivity.
